RX900 S2 Upgrade and Maintenance Manual 251
Management and diagnostics modules
13.2.3 Removing the chassis ID board
Figure 155: Removing the chassis ID board cable from the local service display
Ê Unlock the local service display (1).
Ê Slide the local service display outward so that you can disconnect the
chassis ID board cable (2).
Ê Disconnect the chassis ID board cable (3).
/
