RX900 S2 Upgrade and Maintenance Manual 49
Basic procedures
4.7 Mounting the server in the rack
Inserting the server (if applicable)
Figure 10: Inserting the server
Ê Pull the middle parts of the rails out of the rack completely until they click into
place (1).
I The middle parts of the rails must click into place so that they can no
longer be moved.
Ê Place the server in module direction as close as possible in front of the rack
and lift it to the mounting position.
Trained personnel
/
0
1
2
2
3
3
3
3
