RX900 S2
Upgrade and Maintenance Manual
185
Main memory
Figure 106: CPUM
EMR slot as
signment
9.1.5
Removing the air duct (if a
pplicable)
Figure 107: Re
moving an air
duct
Ê
Pres
s the green buttons (1).
Ê
Lift the handles (2) to disconnect the air duct from the baseboard.
Ê
Carefully pull the air duct up and out (3).
/
2
1
4
0
6
3
5
/
0
/
0
1
184
186
