RX900 S2
Upgrade and Maintenance Manual
327
Cables
15.4.12
Inst
alling the power distributi
on board
Figure 219: Installing the power
distribution board
Ê
Insert the power distribution board in the baseboard (1).
Ê
Connect the power distribution cables to the baseboard (2).
Ê
Fasten the captive screws (3).
Ê
Close the cable clamps (4).
/
0
0
1
1
2
2
326
328
