Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

242 Upgrade and Maintenance Manual RX900 S2
Front panel and external connectors
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12054-001.fm
12.4.3 Removing the PCI Riser
Figure 148: Removing the PCI Riser
Ê Press the green button (1).
Ê Lift the handle (2) to disconnect the PCI Riser (PCIR) from the baseboard.
Ê Pull the PCIR up and out by using the handle (3).
0
1
/
