RX900 S2 Upgrade and Maintenance Manual 201
Processors
10.1.2 Starting the task
Ê Perform the following procedures:
1. "Opening the rack door" on page 40
2. "Shutting down the server" on page 41
3. "Sliding the server out of the rack" on page 42
4. "Opening the server" on page 44
5. "Removing the CPUMEMR" on page 190
10.1.3 Removing the socket cover
Figure 117: Removing the socket cover
Ê Release the socket lever by pressing it downward and outward (1).
Ê Open the socket lever and the processor holder (2).
Ê Hold the socket cover by the two grips between your thumb and index finger
and lift it vertically upward (3).
/
0
1
