366 Upgrade and Maintenance Manual RX900 S2

Appendix

16.5 Expansion card configuration table

Expansion cards require I/O space for Legacy Booting and for OS running. Due

to the limitation of I/O space, see "Baseboard D3144, CPUMEMR D3145, PCIR

D3146 for PRIMERGY RX900 S2 Technical Manual", the basic rules for

installing expansion cards are:

1. Begin with the installation of the SAS and SAS RAID controllers in order of

I/O space assignment order.

2. Continue with the installation of the expansion cards for LAN and FC into the

PCIe slots.

Chipset IOH#1 IOH#2

Bus scan order 3 2 1 5 6 4 7 8

I/O space assignment order within the

I/O Hub (IOH)

12343 21

Hot-plug nnnnnnnn

Gen2 width x8x8x8x8x8x4x8x8

Slot # 12834567

Vendor Type PCIe Max #

LSI SAS 3Gb Gen1 x4 3 x x x x x x

SAS 6Gb Geb 2 x6 3 x x x x x x

Cougar2 Gen 2 x8 1 x

SAS RAID

(WASAT)

Gen 2 x8 2 x

(*1)

Emulex 8G-FCx1 Gen 2 x8 8 x x x x x x

8G-FCx2 Gen 2 x8 8 x x x x x x

FCoE (*2) Gen 2 x8 8 x x x x x x

Qlogic 8G-FCx1 Gen 2 x8 6 x x x x x x

8G-FCx2 Gen 2 x8 6 x x x x x x

Intel GbEx1 Gen 1 x4 8 x x x x x x x

Table 11: Expansion card installation recommendation I/O Hubs IOH#1 and IOH#2
