RX900 S2 Upgrade and Maintenance Manual 365
Appendix
Figure 252 lists the mapping of PCIe slots to I/O Hubs and CPUs.
CPU population order CPU - IOH
mapping
Connected
devices
Remark
4 CPUs 6 CPUs 8 CPUs CPU
No.
IOH
No.
CPU#1 x x x #1 or
#2
#1 ICH10 PCIe #5 to
BMC
CPU#2 x x x BMC (VGA)
GbE#1, GbE#2,
GbE#3,
10GbE#1
PCIe slot #8 Modular
RAID
PCIe slot #1 PCI Riser
PCIe slot #2 PCI Riser
CPU#3 x x x #3 or
#4
#2 PCIe slot #5 PCI Riser;
Gen2x4
CPU#4 x x x PCIe slot #3 PCI Riser
PCIe slot #4 PCI Riser
PCIe slot #6 PCI Riser
PCIe slot #7 PCI Riser
CPU#5 x x #5 or
#6
#3 PCIe slot #9 hot-plug
CPU#6 x x PCIe slot #10 hot-plug
PCIe slot #11 hot-plug
PCIe slot #12 hot-plug
CPU#7 x #7 or
#8
#4 PCIe slot #17 Gen2x4
CPU#8 x PCIe slot #13
PCIe slot #14
PCIe slot #15
PCIe slot #16
Table 10: Mapping of PCIe slots to I/O Hubs and CPUs
