RX900 S2 Upgrade and Maintenance Manual 213
Processors
10.2.7 Installing the heat sink
Figure 127: Installing the heat sink
Ê Remove the residual thermal paste from the underside of the heat sink.
Ê Clean the heat sink using a lint-free cloth.
Ê Carefully place the heat sink onto the processor.
V CAUTION!
Place the heat sink precisely on the threaded holes (see
circle).Careless handling may damage conductors and render the
baseboard useless.
/
