RX900 S2
Upgrade and Maintenance Manual
93
Hard disk and solid state drives
6.4.6
Removing the a
ir guide
Figure 42: Removing
the air g
uide
Ê
Loosen the captive screws (1)
.
Ê
Lift the air guide out of the chas
sis (2).
/
/
0
92
94
