Fujitsu PRIMERGY RX900 S2 - Inserting the CPUMEMR Guide

RX900 S2 Upgrade and Maintenance Manual 301
Cables
15.1.7 Inserting the CPUMEMR guide
Figure 194: Inserting the CPUMEMR guide
Ê Insert the CPUMEMR guide in the installation slot (1).
Ê Fasten the captive screws of the CPUMEMR guide (2).
