Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

138 Upgrade and Maintenance Manual RX900 S2
Expansion cards and BBU
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12050-001.fm
8.5.8 Inserting the dummy module in the slot
Figure 74: Inserting the dummy module in the slot
Ê Carefully insert the removal tool together with the dummy module in the
slot (1).
Ê Insert the slot lock (2) and relock the slot (3).
Ê Close the hot-plug slot (4).
8.5.9 Completing the task
Ê Perform the following procedures to complete the task:
1. "Installing the rear cover" on page 48
2. "Mounting the server in the rack" on page 49
3. "Closing the rack door" on page 51
/
0
1
2
