Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

168 Upgrade and Maintenance Manual RX900 S2
Expansion cards and BBU
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12050-001.fm
8.10.6 Installing the PCI Riser
Figure 98: Installing the PCI Riser
Ê Carefully insert the PCIR in the slot (1).
Ê Lock the PCIR by pushing down the handle (2).
8.10.7 Completing the task
Ê Perform the following procedures to complete the task:
1. "Installing the rear cover" on page 48
2. "Mounting the server in the rack" on page 49
3. "Bringing the server back to operation" on page 51
4. "Closing the rack door" on page 51
0
/

Fujitsu PRIMERGY RX900 S2 Specifications

General

Brand	Fujitsu
Model	PRIMERGY RX900 S2
Category	Server
Language	English
