RX900 S2 Upgrade and Maintenance Manual 167
Expansion cards and BBU
Figure 97: Inserting the Modular RAID controller
Ê Carefully insert the Modular RAID controller in its slot (1).
Ê Insert the slot lock (2) and relock the slot (3).
1
0
/
