RX900 S2 Upgrade and Maintenance Manual 355
Appendix
For detailed information on connectors see "PRIMERGY RX900 S2 Server -
Operating manual".
Figure 245: Power supply unit numbering scheme
4 6x 1 Gbit/s LAN connectors 10 Hot-plug PCIe slots #9 - #12, see
figure 248
5 Power Supply Units (PSU)
#1 - #4, see figure 245
11 PCIe slots #13 - #17, see
figure 248
6 Management LAN connector
Pos. Component Pos. Component
Tabelle 7:
/ 0 1 2
