358 Upgrade and Maintenance Manual RX900 S2
Appendix
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12058-001.fm
The PCIe slots are assigned as follows:
● B: non-hot plug PCIe slots on the PCI Riser
● F: non-hot plug PCIe slot for the Modular Raid controller only
● G: hot-plug PCIe slots
● H: non-hot plug PCIe slots on the baseboard
Figure 249: CPUMEMR numbering scheme
/
2
1
4
0
6
3
5
