IRECTION FR091521, REVISION 1 VIVID S60N/VIVID S70N BASIC SERVICE MANUAL
8-90 Section 8-5 - Electronic Cage Components - Replacement Procedures
PRELIMINARY
8-5-2-5 Cabinet Cage Module Installation Procedure
1.) Position the replacement Cabinet Cage Module on the system chassis and secure it with the five
screws previously removed (four at the rear and one in front) - refer to Figure 8-113.
2.) Refit the Fan for Cabinet Cage Assembly, Peripherals Console and the DVD/CD-RW drive:
3.) Re-connect the cables (previously disconnected).
4) Refit the Sub-Woofer Assembly, BEP and Front End Door Assembly:
5) Refit the covers, previously removed:
6.) Turn ON power to the system.
• Fan for Cabinet Cage Assembly Installation Procedure on page 8 - 137
• Peripherals Console Installation Procedure on page 8 - 165
• DVD/CD-RW Installation Procedure on page 8 - 186
• Sub-Woofer Assembly Installation Procedure on page 8 - 135
• BEP Installation Procedure on page 8 - 97
• Front End Door Assembly Closing and Installation Procedure on page 8 - 87
• Left Rear Cover Removal Procedure on page 8 - 23\
• Right Rear Cover Removal Procedure on page 8 - 20
• Front Cover Removal Procedure on page 8 - 16
• DVD and Printer Cover Removal Procedure on page 8 - 13
• Right Side Cover Removal Procedure on page 8 - 10
• Air Inlet (Left Side) Cover Removal Procedure on page 8 - 7
