Huawei Quidway S6500 Series User Manual

Operation Manual - Port
Quidway S6500 Series Ethernet Switches Chapter 2 Link Aggregation Configuration
Huawei Technologies Proprietary
2-5
2.2.1 Enable/Disable LACP at Port
You should first enable LACP at the ports before performing dynamic aggregation, so
that both parties can agree on adding/deleting the ports into/from a dynamic LACP
aggregation group.
Perform the following configuration in Ethernet port view.
Table 2-1 Enable/disable LACP at port
Operation Command
Enable LACP at the port
lacp enable
Disable LACP at the port
undo lacp enable
By default, LACP is disabled at the port.
Note that:
z You cannot enable LACP at the mirrored port, port with static MAC address
configured, port with static ARP configured, port with 802.1x enabled.
z You are inhibited to enable LACP at the port in a manual aggregation group.
z You can add a port with LACP enabled into a manual aggregation group, but then
the LACP will be disabled on it automatically. Or you can add a port with LACP
disabled into a static LACP aggregation group, and then the LACP will be enabled
automatically.
2.2.2 Create/Delete Aggregation Group
You can use the following command to create a manual aggregation group or static
LACP aggregation group, but the dynamic LACP aggregation group is established by
the system when LACP is enabled on the ports. You can also delete an existing
aggregation group: when you delete a manual aggregation group, all its member ports
are disaggregated; when you delete a static or dynamic LACP aggregation group, its
member ports form one or several dynamic LACP aggregation groups.
Perform the following configuration in system view.
Table 2-2 Create/delete aggregation group
Operation Command
Create an aggregation group
link-aggregation group agg-id mode { manual |
static }
Delete an aggregation group
undo link-aggregation group agg-id
