v 2.0 — March 2023 Altanium Delta5
250 Servo Digital Outputs
Table 14-7 shows other Servo outputs from which you can select.
UltraSync-E Stems At Open This signal tells the IMM that the valve gates are at the Open
position. The At-Open output signal is ON when all of the
conditions that follow are TRUE:
• Movement to the Open position is complete (applicable
when the At-Position Only When Command Completes is
selected)
• No movement on the plate
• Open position is within the At Position tolerance
• If installed, the UltraSync-E drive has completed calibration,
there are no faults, and is prepared to operate
If one of these conditions is no longer TRUE, the At-Open signal
changes to OFF.
This signal can be used to tell the IMM that injection is permitted.
UltraSync-E Stems At Closed This signal tells the IMM that the valve gates are at the Closed
position. The At-Closed output signal is ON when all of the
conditions the follow are TRUE:
• Movement to the Closed position is complete (applicable
when the At-Position Only When Command Completes is
selected)
• No movement on the plate
• Closed position is within the At Position tolerance
• If installed, the UltraSync-E drive has completed calibration,
there are no faults, and is prepared to operate
If one of these conditions is no longer TRUE, the At-Closed signal
changes to OFF.
Table 14-7 Servo Digital Output Selections
Signal Type Signal Condition Position
None - - -
Digital Input Digital Input 1 - 10
The first five digital inputs may be
factory set for the features installed on
your controller, as shown here:
• IMM In Auto
• External At Temperature
• UltraSync-E Stems Open
Command
• UltraSync-E Stems Close
Command
• External Permit Calibration
--
Table 14-6 Output Signals to the IMM (with UltraSync-E) (Continued)
Signal Description
To Next Page
