Juniper MX2020 - Page 418

Figure 193: Unplugging the 240 V China Power Cord an MX2000 Router
g100416
7. Loosen the two captive screws on the locking levers, and pull away from the chassis. See
Figure 194 on page 399.
NOTE: For the MX2020 Router, pull down the PDM3/Input1 and PDM1/Input1 locking
levers to release the PDM from the chassis, and pull up the PDM0/Input0 and
PDM2/Input0 locking levers to release the PDM from the chassis.
NOTE: For the MX2010 and MX2008 Routers, pull down the PDM1/Input1 locking levers
to release the PDM from the chassis, and pull up the PDM0/Input0 locking levers to
release the PDM from the chassis.
398
