NOTE:
The
AC/DC
settings
and
the
screw
locations
are
the
same
for
MX2008,
MX2010,
and
MX2020
routers.
Figure
208:
Removing
the
MX2000
Router
Adjustment
Bar
Locking
Screws
7.
Insert
a
screw
driver
into
each
adjustment
slot
and
slide
the
adjustment
bar
to
the
right
for
DC
configurations
or
to
the
left
for
AC
configurations.
Refer
to
Figure
209
on
page
435
.
434
453
455
