270 Keysight E4980A/AL Precision LCR Meter
Overview of Remote Control
Status Byte
8-
Operation Status Condition Register
The operation status condition register consists of 16 bits, and reflects these
states in its condition bits. Therefore, each time the E4980A/AL’s condition is
changed, its condition bit changes from “0” to “1,” or from “1” to “0.” Table 8-2
below shows each bit of the operation status condition register.
When you read the contents of the operation status condition register using
the :STAT:OPER:COND? query, this register is not cleared. To clear it, change
the device’s operation state by setting all bits to 0.
Operation Status Event Register
The operation status event register consists of 16-bit registers, and each event
bit in the event register corresponds to a condition bit in the operation status
condition register. Each event bit is set to “1” when its corresponding bit in the
condition register makes a “1”-to-“0” transition only. A negative transition filter
is used.
Table 8-2 Operation Status Condition Register Assignments
Bit No. Bit
Weight
Name Description
0 1 Correction Data
Measurement Bit
0: Correction data measurement not in progress
1: Correction data measurement in progress
1 2 unused always 0 (zero)
2 4 unused always 0 (zero)
3 8 List Sweeping bit 0: List sweep measurement not in progress
1: List sweep measurement in progress
4 16 Measuring bit 0: Measurement not in progress
1: Measurement in progress
5 to 15 unused always 0 (zero)
Table 8-3 Operation Status Event Register Assignments
Bit No. Bit
Weight
Name Description
0 1 Correction Data
Measurement Complete Bit
This bit is set to “1” when the OPEN, SHORT, or LOAD
correction data measurement is completed.
1 2 unused always 0 (zero)
2 4 unused always 0 (zero)
3 8 List Sweep Measurement
Complete Bit
This bit is set to “1” when a last sweep point
measurement of the list sweep measurement is
completed.
