172 Keysight E4980A/AL Precision LCR Meter
Save/Recall
Saving/Recalling Instrument Configuration States
6-
Choosing a Register Number
Functional Description
You have to choose one of the register numbers (in the No. field) before saving
or recalling instrument configurations.
Available choices include 0 through 9 when the medium mode is INT (internal
memory), or 10 through 19 when the medium mode is EXT (USB memory).
To choose a register number and save/recall the configurations:
Step 1. Press [Save/Recall].
Step 2. Use the cursor keys to select the No. field of your desired register number.
Step 3. Select your desired action by pressing the appropriate softkey:
Memory Status Information
Functional Description
Each register number is associated with one of the following memory status
values:
Softkey Description
RECALL Recalls the configurations previously saved in the register that
corresponds to your specified register number.
SAVE Saves the configurations into the register that corresponds to your
specified register number.
DELETE Deletes the configurations previously saved in the register that
corresponds to your specified register number.
Status value Description
-1
The register contains non-E4980A/AL configuration information.
1
0 The register contains no configurations.
1 The register does contain configurations.
2 The register contains any configuration that was saved under a
different firmware version or from another E4980A/AL with a
different option(s) equipped.
2
1. This value is not applicable when the medium mode is INT (internal memory).
2. An “Incompatible state file” warning message is displayed. Status information
may fail to be correctly recalled.
