Keysight E4980A/AL Precision LCR Meter 119
Configuring Measurement Conditions (Display and Function Related Settings)
CORRECTION page
Step 6. Press the ON key to enable short correction in successive measurements.
Description of the Softkeys
To enable/disable or otherwise control the behavior of short correction, use the
following softkeys:
Correction Based on User-Specified Frequency Points
Description of Correction Based on User-Specified Frequency Points
Correction based on user-specified frequency points involves performing
open/short/load correction at frequency points specified by user. You can
specify up to 201 frequency points as needed.
For examples and instructions on using the correction features, see “Correction
Functions” on page 204.
In addition to the open/short correction features, the E4980A/AL provides a
load correction feature that allows you to carry out, at your specified frequency
points, load correction using a transfer function determined based on the
relationships between a particular standard’s reference values (pre-measured,
known values) and the standard’s actual measurements. With load correction,
you can compensate for errors that cannot be compensated using open/short
correction.
Open/short/load correction can be performed at up to 201 specified frequency
points, as shown in Figure 4-12. You can define these frequency points using
the SPOT No. fields. To specify the standard’s reference values, use the A and B
fields. Before entering the standard’s reference values, you need to set the
measurement function using the FUNC field. To obtain the standard’s actual
measurements, use the softkey, which appears when you move the cursor into
the FREQ field.
Softkey Description
ON Enables short correction.
OFF Disables short correction.
MEAS
SHORT
Starts short correction.
When the test signal current exceeds a value shown in Table 11-6, a
“Signal source overload” warning appears and measurement may not be
correct. When performing SHORT correction, reduce the test signal level
so that the signal current doesn’t exceed values shown in Table 11-6.

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
