Keysight E4980A User Manual

Keysight E4980A/AL Precision LCR Meter 321
SCPI Command Reference
E4980A/AL commands
Equivalent key No equivalent key is available on the front panel.
*WAI
Syntax *WAI
Description Waits until all commands sent before this command have been executed. The
following commands are then executed. (No Query)
Equivalent key No equivalent key is available on the front panel.
:ABORt
Syntax :ABORt
Description Resets the trigger system. The trigger state is then in the “Idle” state on the
state diagram. (No Query)
Equivalent key [Meas Setup] - MEAS SETUP - REF A - MEAS ABORT
[Meas Setup] - MEAS SETUP - B - MEAS ABORT
[Meas Setup] - CORRECTION - OPEN - MEAS OPEN - ABORT
[Meas Setup] - CORRECTION - SHORT - MEAS SHORT - ABORT
:AMPLitude:ALC
Syntax :AMPLitude:ALC {ON|OFF|1|0}
:AMPLitude:ALC?
Description Enables the Automatic Level Control (ALC).
Parameter
Equivalent key [Meas Setup] - MEAS SETUP - ALC
:APERture
Syntax :APERture {SHORt|MEDium|LONG},<numeric>
:APERture?
Description Sets the measurement time mode and the averaging rate.
Description
ON or 1 Enables the Automatic Level Control
OFF or 0 (Preset value) Disables the Automatic Level Control

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
