Keysight E4980A/AL Precision LCR Meter
User’s Guide
5 System Configurations
This chapter provides information on the various settings accessible through
the SYSTEM MENU page of the E4980A/AL.
SYSTEM INFO Page
Press the [System] key to open the SYSTEM INFO page. This page displays the
system information of the E4980A/AL, and it allows you to configure each of
the following measurement controls with the cursor placed in the
corresponding field (denoted in parentheses).
• Handler interface (HANDLER I/F field)
• Scanner interface (SCANNER I/F field)
Figure 5-1 shows the fields available on this page along with their
corresponding softkeys.
Figure 5-1 SYSTEM INFO Page
㪼㪋㪐㪏㪇㪸㫌㪼㪈㪈㪋㪋
㪑㩷㩷㪝㫀㪼㫃㪻
㪑㩷㩷㪤㫆㫅㫀㫋㫆㫉

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
