Keysight E4980A User Manual

346 Keysight E4980A/AL Precision LCR Meter
SCPI Command Reference
E4980A/AL commands
10-
[Meas Setup] - MEAS SETUP - DCR RNG - HOLD
:FUNCtion:DCResistance:RANGe[:VALue]
Syntax :FUNCtion:DCResistance:RANGe[:VALue] <numeric>
:FUNCtion:DCResistance:RANGe[:VALue]?
Description Selects the DCR measurement range. This command turns the auto range
function OFF.
Parameter
Equivalent key [Meas Setup] - MEAS SETUP - DCR RNG
:FUNCtion:DEV[1-2]:MODE
Syntax :FUNCtion:DEV[1-2]:MODE {ABSolute|PERCent|OFF}
:FUNCtion:DEV[1-2]:MODE?
Description Selects the deviation measurement mode.
Parameter
Equivalent key [Meas Setup] - MEAS SETUP - DEV A - ABS
[Meas Setup] - MEAS SETUP - DEV A - %
[Meas Setup] - MEAS SETUP - DEV A - OFF
[Meas Setup] - MEAS SETUP - DEV B - ABS
[Meas Setup] - MEAS SETUP - DEV B - %
[Meas Setup] - MEAS SETUP - DEV B - OFF
<Numeric>
Range 10|100|1k|10k|100k
Preset value 100
Unit ohms
Description
ABSolute Sets the deviation measurement mode to “ABS”
PERCent Sets the deviation measurement mode to “%”
OFF(Preset value) Disables the deviation measurement mode

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
