Keysight E4980A User Manual

Keysight E4980A/AL Precision LCR Meter 25
Unpacking and Preparation
Caution when Using the Handle
Caution when Using the Handle
Follow the instructions below when using the E4980A/AL’s handle, otherwise
you may get your fingers caught in the handle or the E4980A/AL may fall and
be damaged
• When the handle is set up as shown in Figure 1-5, do not put any additional
weight onto the E4980A/AL or lift it suddenly.
• Do not touch the handle while the DUT is attached.
Figure 1-5 The handle in the set-up position
㪼㪋㪐㪏㪇㪸㫌㫁㪈㪈㪎㪌

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
