Keysight E4980A User Manual

152 Keysight E4980A/AL Precision LCR Meter
System Configurations
SYSTEM INFO Page
5-
Handler Interface
Functional Description
When equipped with Option 201 Handler Interface, the E4980A/AL can
interact with the handler. The 36-contact Amphenol connector on the rear
panel is used to connect the interface, through which control input/output
signals and comparator bin sorting result signals are communicated.
For more information on available options, see Appendix E , “Handler
Interface,” on page 455.
When the E4980A/AL is not equipped with the Handler Interface, the
HANDLER I/F field shows a “NOT INSTALLED” message and the ON/OFF
settings are not available.
Softkey Description
ON Turns ON the handler interface feature.
OFF Turns OFF the handler interface feature.

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
