Keysight E4980A/AL Precision LCR Meter 341
SCPI Command Reference
E4980A/AL commands
Equivalent key [Display Format] - DISPLAY FORMAT
[Display Format] - BIN No.
[Display Format] - BIN COUNT
[Display Format] - LIST SWEEP
[Meas Setup] - MEAS SETUP
[Meas Setup] - CORRECTION
[Meas Setup] - LIMIT TABLE
[Meas Setup] - LIST SETUP
[Save/Recall]
[System] - SYSTEM INFO
[System] - SYSTEM CONFIG
[System] - SELF TEST
[System] - SERVICE
:DISPlay[:WINDow]:TEXT[1-2][:DATA]:FMSD:DATA
Syntax :DISPlay[:WINDow]:TEXT[1-2][:DATA]:FMSD:DATA <most significant digit>
:DISPlay[:WINDow]:TEXT[1-2][:DATA]:FMSD:DATA?
BCOunt Sets displayed page to <BIN COUNT DISPLAY>
LIST Sets displayed page to <LIST SWEEP DISPLAY>
MSETup Sets displayed page to <MEAS SETUP>
CSETup Sets displayed page to <CORRECTION>
LTABle Sets displayed page to <LIMIT TABLE SETUP>
LSETup Sets displayed page to <LIST SWEEP SETUP>
CATAlog Sets displayed page to <CATALOG>
SYSTem Sets displayed page to <SYSTEM INFO>
SELF Sets display page to <SELF TEST>
MLARge Sets page to display measurement results in large
characters
SCONfig Sets displayed page to <SYSTEM CONFIG>
SERVice Sets displayed page to <SERVICE>
Description

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
