Keysight E4980A User Manual

Keysight E4980A/AL Precision LCR Meter 351
SCPI Command Reference
E4980A/AL commands
Equivalent key No equivalent key is available on the front panel.
:FUNCtion:SMONitor:VDC[:STATe]
Syntax :FUNCtion:SMONitor:VDC[:STATe] {ON|OFF|1|0}
:FUNCtion:SMONitor:VDC[:STATe]?
Description Enables the DC voltage-level monitor function.
Parameter
Equivalent key [Meas Setup] - MEAS SETUP - VDC MON - ON
[Meas Setup] - MEAS SETUP - VDC MON - OFF
:HCOPy:SDUMp:DATA
Syntax :HCOPy:SDUMp:DATA
Description Outputs screen image to the controller. (Query Only)
Example of Use
Dim Nop As Long
Dim GifData(10000) As Byte
Dim paramsArray(2) As Long
Dim i As Integer
Nop = UBound(GifData) - LBound(GifData) + 1
paramsArray(0) = VarPtr(Nop)
paramsArray(1) = VarPtr(GifData(0))
Call viVPrintf(AgtE4980A/AL, ":HCOPY:SDUMP:DATA?" + vbLf, 0)
Call viVScanf(AgtE4980A/AL, "%#b", paramsArray(0))
OFF or 0 Does nothing
Description
This is available when option 001 is installed.
Description
ON or 1 DC voltage monitor function ON
OFF or 0 (Preset value) DC voltage monitor function OFF

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
