Keysight E4980A/AL User’s Guide-423
Keysight E4980A/AL
Precision LCR Meter
User’s Guide
A Manual Changes
This appendix shows manual changes that need to be made to an earlier
revision according to firmware or serial number.
Manual Changes
If your E4980A/AL has the firmware or serial number shown in Table A-1 and
Table A-2, see the corresponding manual changes.
The ten-character serial number is stamped on the serial number plate (Figure
A-1) on the rear panel.
Figure A-1 Example of Serial Number Plate
Table A-1 Manual Changes by Firmware Number
Firmware Number Make Manual Changes
A.02.00 and later Change 1
A.02.10 and later Change 2
A.02.11 and later Change 3
A.03.00 and later Change 4
Table A-2 Manual Changes by Serial Number
Serial Number Make Manual Changes
MY464/SG464 and below for E4980A
MY542/SG542 and below for E4980AL
Change 5

Keysight E4980A Specifications

General

Frequency Range	20 Hz to 2 MHz
Basic Accuracy	0.05%
DC Bias Voltage	0 V to ±40 V
Measurement Functions	L, C, R, Z, D, Q
DC Bias Current	0 A to 20 mA (using external DC bias source)
Display	LCD
Interface	LAN, USB, GPIB
Dimensions	426 mm (W) x 177 mm (H)
Weight	13.5 kg
