Page #345 background imageLoading...
Page #345 background image
Keysight E4980A/AL Precision LCR Meter 345
SCPI Command Reference
E4980A/AL commands
Example of Use viVPrintf(AgtE4980A/AL, ":FORM REAL" + vbLf, 0)
Equivalent key No equivalent key is available on the front panel.
:FREQuency[:CW]
Syntax :FREQuency[:CW] <numeric>
:FREQuency[:CW]?
Description Sets the frequency for normal measurement.
Parameter
Equivalent key [Display Format] - MEAS DISPLAY - FREQ
[Meas Setup] - MEAS SETUP - FREQ
:FUNCtion:DCResistance:RANGe:AUTO
Syntax :FUNCtion:DCResistance:RANGe:AUTO {ON|OFF|1|0}
:FUNCtion:DCResistance:RANGe:AUTO?
Description Enables the auto range function for DCR measurement.
Parameter
Equivalent key [Meas Setup] - MEAS SETUP - DCR RNG - AUTO
REAL Sets the transfer mode to Binary
Description
<Numeric>
Range
20 to 2M
1
Preset value 1k
Unit Hz
Resolution Depends on the setting frequency.
1. The range varys depending on the frequency option.
Description
ON or 1 (Preset value) DCR measurement auto range ON
OFF or 0 DCR measurement auto range OFF
