Keysight E4980A - Monitor Information

Keysight E4980A/AL Precision LCR Meter 75
Display Format
MEAS DISPLAY Page
Monitor Information
The following describes monitor information displayed on the MEAS DISPLAY
page. This information cannot be changed on the MEAS DISPLAY page.
Monitor
information
Description
VAC Displays the test signal voltage level (AC voltage). Displays
measurement results regardless of the type of measurement
parameter
IAC Displays the test signal current level (AC current). Displays
measurement results regardless of the type of measurement
parameter
VDC Displays the DC bias voltage level (DC voltage). Set the VDC MON
field of the [Means Setup] page to ON when you want to display it.
1
IDC Displays the DC bias current level (DC current). Set the IDC MON field
of the [Means Setup] page to ON when you want to display it
CORR Displays the correction information of enabled correction types
(OPEN/SHORT/LOAD) and cable length
CH
Displays the channel number in the multi-correction mode
2
1. This can be displayed only when option 001 is installed.
2. SINGLE is displayed when option 301 is not installed.
The VDC/IDC monitor values are the ones measured under the condition
that the setting value of the test signal level (LEVEL field) is output.
Therefore, these values are different from the measurement results
displayed when the measurement parameter is DC voltage
measurement/DC current measurement (Vdc-Idc).
