150 Keysight E4980A/AL Precision LCR Meter
Configuring Measurement Conditions (Display and Function Related Settings)
LIST SWEEP SETUP Page
4-
Step 6. Have all sweep points between the start and end points automatically
entered by pressing the appropriate softkey:
Softkey Description
FILL LINEAR Linearly enters all sweep points between the start and end points.
FILL LOG Logarithmically enters all sweep points between the start and end
points.
1
1. Available only when using the frequency as the list sweep parameter.
If n is not found, calculation is made on the assumption that n=1
represents the minimum value.
If m is not found, calculation is made on the assumption that m=201
represents the maximum value.
