2N8/2N7
1-3-26
U018
If the verified result was incorrect, the following are displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U019 Firmware Version
Description
Displays the part number of the firmware version to each PWB.
Purpose
To check the part number or to decide, if the newest version of firmware is installed.
Method
1. Press the start key. The firmware version are displayed.
2. Change the screen using the cursor up/down keys.
Item No. Description
Display Description
f001 An expected-value file does not exist.
f002 Reading the expected-value file failed.
f003 Illegal data in the expected-value file (not 64-byte data)
s001t Failure to read the checksum
NG The expected value and the checksum do not match.
Display Description
Main Main firmware
MMI Main operation firmware
Panel Main Operation firmware
Panel Boot Operation booting
Browser Browser firmware
Engine Engine firmware
Engine Boot Engine booting
Scanner Scanner firmware
Scanner Boot Scanner booting
RFID RFID firmware
IH CPU IH CPU firmware
IH CPU Boot IH CPU booting
Motor CPU Motor CPU firmware
Motor CPU Boot Motor CPU booting
Dictionary Dictionary software
Option Language Optional language software
OCR OCR software
To Next Page
