2N8/2N7
1-3-183
U520 Set TDRS
Description
Perform TDRS settings and information views.
Purpose
Perform TDRS settings and information views.
Method
1. Press the start key.
2. Select the item.
Setting: [Registration]
1. Select the item.
Setting: [Access Code]
1. Select the item.
* : The status of Online or Offline will be indicated at the right bottom depending on connec-
tion with TDRS Manager.
The Regist button is inoperative if the USB is not installed.
A normal completion will be indicated by Complete in the status of the item that was per-
formed.
An occurrence of an error is indicated by an error number in the status of the item that
was performed.
If [User/Processing Registration using a Password] is selected in the previous dialog, the
TDRS User will be indicated.
If [Processing Registration using an Access Code] is selected, the Access Code will be
indicated.
Item No. Description
Display Description
Registration Transition to the TDRS Manager registering dialog
Information Transition to the Device Agent description dialog
On/Off Config Transition to the TDRS features dialog
Display Description
TDRS User Registering process using user and password
Access Code Registering process using an Access Code
Display Description
Regist Performing registration to TDRS Manager
TDRS Server TDRS Server URL
TDRS User TDRS Username
Access Code TDRS Access Code
Proxy Server TDRS Proxy Server URL
Proxy Port TDRS Proxy Port Number
Proxy User TDRS Proxy Username
Text TDRS Description
