2N8/2N7-4
1-3-129
U247 Setting the paper feed device
Description
Turn on motor and clutches of paper feeder device.
Purpose
To check the operation of motor and clutches of paper feed device.
Method
1. Press the start key.
2. Select the paper feed device.
Method: [LCF/Side LCF]
1. Press [Motor] or [Clutch] and select the item.
2. Select [Execute].
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Item No. Description
Display Description
LCF Large capacity feeder
Side Deck Side deck
SMT Side multi tray
Side 2PF Side paper feeder
Side LCF Side large capacity feeder
Display Description
Motor Off PF paper feed motor (PFPFM) is turned off
On PF paper feed motor (PFPFM) is turned on
Clutch C1 Clutch PF paper feed clutch 1 (PFPFCL1) is turned on
C2 Clutch PF paper feed clutch 2 (PFPFCL2) is turned on
V Feed Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
H Feed1 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
H Feed2 Clutch PF paper conveying clutch 3 (PFPCCL3) is turned on
Execute Executing the action
