Kyocera TASKalfa 6501i - Adjusting the Hinge

2N8/2N7
1-5-128
(6) Adjusting the hinge
Perform this adjustment when the DP trails down when it is open.
Procedure
1. Open the DP.
2. Rotate the adjusting screws at the front
of the left hinge using a flat screwdriver
so that the DP won’t trail down.
3. Close the document processor when
adjustment was done.
Figure 1-5-212
DP
Left hinge
Adjusting screw
