Kyocera TASKalfa 6501i - Installing the Toner Disposal Box

2N8/2N7-1
1-2-27
1. Remove the tape.
2. Remove the cable cover.
Figure 1-2-45
3. Fit the toner disposal box using three
M3 x 8 S tight screws.
Figure 1-2-46
Installing the toner disposal box
Tap e
Cable cover
Toner disposal box
Toner disposal
box
Toner disposal
box
Screw
Screw
Screw
Screw
Screws
