Kyocera TASKalfa 6501i - List of Correspondences of PWB Names

2N8/2N7
2-2-4
List of correspondences of PWB names
*: 220 to 240 V specifications only.
No. Name used in service manual Part No. Name used in parts list
1
Main PWB (MPWB) 302N794110
302N794120
120 V Specification Model:
PARTS PWB MAIN ASSY SP
230 V Specification Model:
PARTS PWB MAIN ASSY SP EU
2 Engine PWB (EPWB) 302N794100 PARTS PWB ENGINE ASSY SP
3 Power source PWB (PSPWB) 302LF94260 PARTS UNIT LOW VOLTAGE SP
4 High voltage PWB (HVPWB) 302LF94260 PARTS UNIT HIGH VOLTAGE MAIN SP
5 ISC PWB (ISCPWB) 302N494201 PARTS PWB ISC ASSY SP
6 CCD PWB (CCDPWB) -
7 LED lamp PWB (LLPWB) -
8 Front PWB (FRPWB) 302LF94210 PARTS PWB FRONT MONO ASSY SP
9 Feed PWB 1 (FPWB1) 302N494160 PARTS PWB FEED 1 ASSY SP
10 Feed PWB 2 (FPWB2) 302N494170 PARTS PWB FEED 2 ASSY SP
11 Relay PWB (RPWB) 302K994201 PARTS PWB JUNCTION ASSY SP
12 LSU relay PWB (LSURPWB) 302N994080 PARTS PWB LSU JUNC MONO ASSY SP
13 APC PWB (APCPWB) -
14 PD PWB (PDPWB) -
15 Drum PWB (DRPWB) -
16
Fuser IH PWB (FIHPWB) 302N794030
302N794040
120 V Specification Model:
PARTS IH BOX ASSY J SP
230 V Specification Model:
PARTS IH BOX ASSY E SP
17 Eject PWB (EJPWB) 302LF94230 PARTS PWB EXIT ASSY SP
18 RFID PWB (RFPWB) 302K394070 PARTS PWB RFID ASSY SP
19 Interface PWB (IFPWB) 302K994270 PARTS PWB KUIO ASSY SP
20 PF main PWB (PFMPWB)
303NF94060
PARTS PWB FRONT DECK ASSY SP
21 BR main PWB (BRMPWB)
302K994830
PARTS PWB BRIDGE ASSY SP
22 JS main PWB (JSMPWB)
302K994600
PARTS PWB JOB SEPA ASSY SP
23 DP relay PWB (DPRPWB)
303P294010
PARTS PWB DPIF ASSY SP
24 Current PWB (CRPWB)* 302LF94230 PARTS PWB CURRENT AVE ASSY SP
25 Operation PWB 1 (OPWB1)
302N294150
PARTS PWB PANEL MAIN ASSY J SP
26 Operation PWB 2 (OPWB2)
302N294160
PARTS PWB OPERATION ASSY SP
27 Operation PWB 3 (OPWB3)
302N294170
PARTS PWB OPERATION LED ASSY SP
