Kyocera TASKalfa 6501i - Electrical Parts that Could Cause Paper Jam at the BR (Bridge) Part

2N8/2N7
1-4-52
(10) Electrical parts that could cause paper jam at the BR (bridge) part
Timing of detection
Corrective Action
Jam code
J490x,J491x,J500x,J501x,J510x,J511x
Related parts
BR conveying motor 1 (BRCM1) BR feedshift solenoid (BRSOL)
BR conveying motor 2 (BRCM2) Engine PWB (EPWB)
BR conveying sensor 1 (BRCS1) BR PWB (BRPWB)
BR conveying sensor 2 (BRCS2)
BR eject sensor (BRES)
Checking
procedure at the
occurrence of
J49XX
Corrective action at the occurrence of
J49XX
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks see page 1-4-26
2
BR conveying sensor 1 (BRCS1):
Conduct connectivity check, mounting
location check, operation check (U031)
BR PWB YC6-2
3
BR conveying motor 1 (BRCM1):
Operation check (U030)
BR PWB YC7-1 to 4
4
BR PWB (BRPWB): Replace
5
Engine PWB: Replace
Checking
procedure at the
occurrence of
J50XX
Corrective action at the occurrence of
J50XX
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks see page 1-4-26
2
BR conveying sensor 2 (BRCS2):
Conduct connectivity check, mounting
location check, operation check (U031)
BR PWB YC4-2
3
BR conveying motor 2 (BRCM2):
Operation check (U030)
BR PWB YC7-5 to 8
4
BR PWB (BRPWB): Replace
5
Engine PWB: Replace
