*: When taking out the machine, a space for
machine rear requires approximately 2 m.
1. Remove the hinge joints, and then
remove the outer case, the inner case,
the top left/right pads, the left/right
stays, the front pad, the upper spacer,
the operation arm and the bottom
spacer.
2. Cut four tapes of the skid each corner.
3. Cut each tape which locks the slopes
and the bottom left/right pads.
Figure 1-2-6
4. Rotate slopes as shown in the figure
and make them for machine sliding.
Figure 1-2-7
Tap e
Tap e
