2N8/2N7
1-2-8
5. Check that there is no level difference in
slopes (circle section of figure 1-2-7).
6. Open the machine cover.
7. Lift the machine each left and right one
side, and then remove the bottom left
and right pads and machine cover.
Figure 1-2-8
8. Move the machine alongside slopes to
slide to the floor.
Figure 1-2-9
Bottom right pad
Bottom left pad
Slope
Slope
Slope
Slope
To Next Page
