2N8/2N7
1-3-67
U099 Adjusting original size detection
Description
Checks the operation of the original size detection and sets the sensing threshold value.
Purpose
Modify the threshold of detection if documents are frequently mal-detected in size after scanning
a wholly dark document or a document enclosed with dark objects on edges.
Method
1. Press the start key.
2. Select the item.
Method: [Data1/Data2]
1. Place the original and close the original cover or DP
2. The light source illuminates and the CCD sensor determines the width of the document. The
original size sensor determines the document is vertical or horizontal. (The document is
detected two times when the DP is installed.)
Item No. Description
Display Description
Data1 Displays the width of an Original Area colored original document
B/W Level1 Setting original size detection threshold value
Data2 Displays the width of an Original Area colored original document (when
DP is installed)
Display Description
Original Area R Detected original width size for color R
Original Area G Detected original width size for color G
Original Area B Detected original width size for color B
Original Area Detected original width size
Size SW L Displays the original size sensor (OSS) ON/OFF
(Sensor OFF/ ON: 0/ 1)
To Next Page
