Kyocera TASKalfa 6501i - Feedshift; Switchback Sections; Detaching and Refitting Job Separator

2N8/2N7
1-5-71
1-5-8 Feedshift/ switchback sections
(1) Detaching and refitting job separator
Procedure
1. Remove the fuser unit (see page 1-5-
67).
2. Remove the right upper cover (see
page 1-5-9).
3. Remove the connector.
4. Remove two screws and the remove
the job separator.
Figure 1-5-116
Connector
Screw
Screw
Job separator
