2N8/2N7
1-4-45
3
MP lift sensors 1 and 2: Check for
connection and the position of the sensor
to be mounted.
Relay PWB (YC3-5, YC3-8) (YC12)
4
MP lift motor: Check if the paper lift base
is raised as the motor rotates.
Relay PWB(YC3-11), (YC12)
5
Feed PWB 1: Replace
Feed PWB 1(YC17),(YC1)
6
Engine PWB: Replace
Engine PWB (YC6)
Checking
procedure at the
occurrence of
J0131
Corrective action at the occurrence of
J0131
On/Off control signal output connector
(terminal), point of checking connection
To Next Page
