2N8/2N7
1-2-18
2. Press the guide lock lever to release
the lock.
3. Grasp the paper width adjusting tab and
move the paper width guides to fit the
paper.
Figure 1-2-28
4. Align the paper flush against the right
side of the cassette.
*: Before loading the paper, be sure that it is
not curled or folded.
*: Ensure that the loaded paper does not
exceed the level indicated.
*: Make sure that the paper length guide
and the paper width guides are correctly
abut with the paper. Be sure to remove
spaces between the guides and the
paper.
Figure 1-2-29
Guide lock lever
Paper width
adjusting tab
Paper width guides
Paper
To Next Page
