6. Remove four screws and then remove
the ISU.
Figure 1-5-73
Refitting the ISU
1. Install the FFT.
*: The FFT should be inserted while hold-
ing the position (A) shown in the illustra-
tion (A).
Figure 1-5-74
1
3
5
7
9
2
4
6
8
4
2468
13579
ScrewScrew
Screw
ISU
Screw
A
A
1
2
