Kyocera TASKalfa 6501i - Page 751

2N8/2N7
1-5-139
Figure 1-5-227
Bridge fan motor
(Rating label:outside)
Toner fan motor
(Rating label:outside)
Controller fan motor
(Rating label:inside)
Fuser rear fan motor
(Rating label:outside)
Exhaust fan motor 1
(Rating label:outside)
Exhaust fan motor 2
(Rating label:inside)
Exhaust fan motor 3
(Rating label:inside)
DP fan motor
(Rating label:inside)
Power sourace fan motor
(Rating label:inside)
LSU fan motor
(Rating label:inside)
Eject rear fan motor
(Rating label:outside)
